1.3-inch SH1106 128×64 OLED Display (I²C)

A 1.3-inch 128×64 SH1106 OLED with I²C support for the optional Pi Thermal Camera display.

Description
Reviews (0)

Description

This 1.3-inch 128×64 OLED uses the SH1106 controller and supports I²C, matching the optional display described by the Meow Meow Scratch Pi Thermal Camera project.

Project compatibility

Select/configure the I²C version or mode, not SPI.
Power and signal it at 3.3V for Raspberry Pi use.
The project expects address 0x3C and the SH1106 driver through luma.oled; confirm the address with i2cdetect.
This is not interchangeable with the separate PiicoDev SSD1306 display without code changes.

Choose the desired display colour on the merchant page.
